赫斯曼交换机2019年产品
Date:2018-11-30 12:00:25

www.hesimann.com

943892001

OCTOPUS 5TX EEC

IP67 unmanaged switch with 5 4-pin M12-D 100BASETX Ports

943931001

OCTOPUS 8M

IP67 fully Managed switch with 8 4-pin M12-D 100BASETX Ports

943967101

OCTOPUS 8M-6PoE

IP67 fully Managed PoE switch with 8 * 4-pin M12-D 100BASETX Ports

943967001

OCTOPUS 8M-8PoE

IP67 fully Managed PoE switch with 8 * 4-pin M12-D 100BASETX Ports

943912001

OCTOPUS 16M

IP67 fully Managed switch with 16 4-pin M12-D 100BASETX Ports

943912002

OCTOPUS 16M-2FX

IP67 fully Managed Switch with 14 4-pin M12-D 100BaseTX ports plus 2

ports 100BASE-FX (microFX)

943960001

OCTOPUS 16M-8PoE

IP67 fully Managed PoE Switch with 16 4-pin M12-D 100BaseTX

943960101

OCTOPUS 16M-8PoE-2FX

IP67 fully Managed PoE Switch with 14 4-pin M12-D 100BaseTX ports plus

2 ports 100BASE-FX (microFX)

943923001

OCTOPUS 24M

IP67 fully Managed Switch with 24 4-pin M12-D 100BaseTX ports and

support IP67 protected auto-configuration adaptor

943923002

OCTOPUS 24M-2FX

IP67 fully Managed Switch with 22 4-pin M12-D 100BaseTX ports plus 2

ports 100BASE-FX (microFX)

943944001

OCTOPUS M12-MiniPower Adaptor

M12-MiniPower Adaptor for OCTOPUS





M12 V.24 serial interface terminal cable for the local connection of an

943902001

OCTOPUS, Terminal Cabel

external management station (VT100 terminal or PC with appropriate

terminal emulation).

934578004

EM12S 001L0100 OCTOPUS

Industrial ETHERNET patch cords with 2 x M12 connector "D"-coded

according to IEC 61076-2-101





943639002

RH1-TP

4 ports 10BASE-T. All ports half-duplex.

943701002

RH1-CX+ (NAVY)

2 ports 10BASE-T, 1 port 10BASE-2 (BNC) & 1 port 10BASE-FL,

multimode, ST socket. All ports half-duplex.

943658002

RT2-TX/FX

Industrial Fast Ethernet transceiver with 1 port 100BASE-TX & 1 port

100BASE-FX multimode, SC socket

943658032

RT2-TX/FX-SM

Industrial Fast Ethernet transceiver with 1 port 100BASE-TX & 1 port

100BASE-FX, singlemode, SC socket

943890001

SPIDER 1TX/1FX

1 port 100BASE-TX & 1 port 100BASE-FX multimode, SC socket. No

redundant power inputs, no fault relay





943891001

SPIDER 1TX/1FX-SM

1 port 100BASE-TX & 1 port 100BASE-FX singlemode, SC socket. No

redundant power inputs, no fault relay

943927001

SPIDER 1TX/1FX EEC

1 ports 100BASE-TX & 1 port 100BASE-FX multimode, SC socket. EEC (-

40 to +70ºC). No redundant power inputs, no fault relay

943928001

SPIDER 1TX/1FX-SM EEC

1 ports 100BASE-TX & 1 port 100BASE-FX singlemode, SC socket. EEC (-

40 to +70ºC). No redundant power inputs, no fault relay

943899001

SPIDER 3TX-TAP

3 ports 100BASE-TX. No redundant power inputs, no fault relay

943221001

SPIDER 4TX/1FX

4 ports 100BASE-TX & 1 port 100BASE-FX multimode, SC socket. No

redundant power inputs, no fault relay

943221101

SPIDER 4TX/1FX EEC

4 ports 100BASE-TX & 1 port 100BASE-FX multimode, SC socket. EEC (-

40 to +70ºC). No redundant power inputs, no fault relay

943880001

SPIDER 4TX/1FX-SM EEC

4 ports 100BASE-TX & 1 port 100BASE-FX singlemode, SC socket. EEC (-

40 to +70ºC). No redundant power inputs, no fault relay

943914001

SPIDER 4TX/1FX-ST EEC

4 ports 100BASE-TX & 1 port 100BASE-FX multimode, ST socket. EEC (-

40 to +70ºC). No redundant power inputs, no fault relay

943824002

SPIDER 5TX

5 ports 100BASE-TX. No redundant power inputs, no fault relay

943824102

SPIDER 5TX EEC

5 ports 100BASE-TX. EEC (-40 to +70ºC). No redundant power inputs, no

fault relay

943376001

SPIDER 8TX

8 ports 100BASE-TX. No redundant power inputs, no fault relay

943376201

SPIDER 8TX EEC

8 ports 100BASE-TX. EEC (-40 to +70ºC). No redundant power inputs, no

fault relay

943957001

SPIDER II 8TX

8 ports 100BASE-TX. No redundant power inputs, no fault relay

943958001

SPIDER II 8TX EEC

8 ports 100BASE-TX. EEC (-40 to +70ºC). No redundant power inputs, no

fault relay

943958111

SPIDER II 8TX/1FX EEC

8 ports 100BASE-TX & 1 port 100BASE-FX Multimode, SC socket. EEC (-

40 to +70ºC). No redundant power inputs, no fault relay

943958131

SPIDER II 8TX/1FX-SM EEC

8 ports 100BASE-TX & 1 port 100BASE-FX Singlemode, SC socket. EEC (-

40 to +70ºC). No redundant power inputs, no fault relay

943958121

SPIDER II 8TX/1FX-ST EEC

8 ports 100BASE-TX & 1 port 100BASE-FX multimode, ST socket. EEC (-

40 to +70ºC). No redundant power inputs, no fault relay

943958211

SPIDER II 8TX/2FX EEC

8 ports 100BASE-TX & 2 port 100BASE-FX Multimode, SC socket. EEC (-

40 to +70ºC). No redundant power inputs, no fault relay

943958231

SPIDER II 8TX/2FX-SM EEC

8 ports 100BASE-TX & 2 port 100BASE-FX Singlemode, SC socket. EEC (-

40 to +70ºC). No redundant power inputs, no fault relay

943958221

SPIDER II 8TX/2FX-ST EEC

8 ports 100BASE-TX & 2 port 100BASE-FX multimode, ST socket. EEC (-

40 to +70ºC). No redundant power inputs, no fault relay

943962002

SPIDER II Giga 5T EEC

5 ports 100/1000 BASE-TX. EEC (-40 to +70ºC). No redundant power

inputs, no fault relay

943963002

SPIDER II Giga 5T/2S EEC

5 ports 100/1000 BASE-TX., 2 GE SFP slot, EEC (-40 to +70ºC). No

redundant power inputs, no fault relay

943771001

RS2-3TX/2FX EEC

3 ports 100BASE-TX & 2 ports 100BASE-FX multimode, SC socket. EEC (-

40 to +70ºC), w/ redundant power inputs & fault relay





3 ports 100BASE-TX & 2 ports 100BASE-FX singlemode, SC socket. EEC (

943772001

RS2-3TX/2FX-SM EEC

40 to +70ºC), w/ redundant power inputs & fault relay

943819001

RS2-4TX EEC

4 ports 100BASE-TX, EEC (-40 to +70ºC), w/ redundant power inputs &

fault relay

943773001

RS2-4TX/1FX EEC

4 ports 100BASE-TX & 1 port 100BASE-FX multimode, SC socket. EEC (-

40 to +70ºC), w/ redundant power inputs & fault relay

943774001

RS2-4TX/1FX-SM EEC

4 ports 100BASE-TX & 1 port 100BASE-FX singlemode, SC socket. EEC (-

40 to +70ºC), w/ redundant power inputs & fault relay

943119002

RS2-4TX/1FX-ST EEC

4 ports 100BASE-TX & 1 port 100BASE-FX singlemode, ST socket. EEC (-

40 to +70ºC), w/ redundant power inputs & fault relay

943732003

RS2-5TX

5 ports 100BASE-TX, w/ redundant power inputs, no fault relay. Die-cast

housing.

943732102

RS2-5TX/FX

4 ports 100BASE-TX & 1 port 100BASE-FX, multimode, MTRJ socket, w/

redundant power inputs, no fault relay. Die-cast housing.

943686003

RS2-TX

8 ports 100BASE-TX, w/ redundant power inputs & fault relay





943434047

RS20-1600T1T1SDAUHC

14 ports 10/100BASE-T(X) & 2 uplink ports 100BASE-TX, w/ redundant

power inputs & fault relay

943434048

RS20-1600M2M2SDAUHC

14 ports 10/100BASE-T(X) & 2 uplink ports 100BASE-FX Multimode SC

socket.. w/ redundant power inputs & fault relay





14 ports 10/100BASE-T(X) & 1 uplink port 100BASE-TX, 1 uplink port

943434049

RS20-1600M2T1SDAUHC

100BASE-FX multimode, SC socket.. w/ redundant power inputs & fault

relay





14 ports 10/100BASE-T(X) & 1 uplink port 100BASE-TX, 1 uplink port

943434051

RS20-1600S2T1SDAUHC

100BASE-FX singlemode, SC socket.. w/ redundant power inputs & fault

relay





14 ports 10/100BASE-T(X) & 1 uplink port 100BASE-FX multimode, 1

943434052

RS20-1600S2M2SDAUHC

uplink port 100BASE-FX singlemode, SC socket.. w/ redundant power

inputs & fault relay

943434053

RS20-1600S2S2SDAUHC

14 ports 10/100BASE-T(X) & 2 uplink ports 100BASE-FX singlemode SC

socket.. w/ redundant power inputs & fault relay





14 ports 10/100BASE-T(X) & 1 uplink port 100BASE-TX, 1 uplink port

943434054

RS20-1600L2T1SDAUHC

100BASE-FX longhaul singlemode, SC socket.. w/ redundant power inputs

& fault relay





14 ports 10/100BASE-T(X) & 1 uplink port 100BASE-FX multimode, 1

943434055

RS20-1600L2M2SDAUHC

uplink port 100BASE-FX longhaul singlemode, SC socket.. w/ redundant

power inputs & fault relay





14 ports 10/100BASE-T(X) & 1 uplink port 100BASE-FX singlemode, 1

943434056

RS20-1600L2S2SDAUHC

uplink port 100BASE-FX longhaul singlemode, SC socket.. w/ redundant

power inputs & fault relay

943434057

RS20-1600L2L2SDAUHC

14 ports 10/100BASE-T(X) & 2 uplink ports 100BASE-FX longhaul

singlemode SC socket.. w/ redundant power inputs & fault relay





6 ports 10/100BASE-T(X) & 3 ports 100BASE-FX ST multimode,

943434058

RS20-0900NNM4TDAUHC

unmanaged, Extended Temperature, w/ redundant power inputs & fault

relay





6 ports 10/100BASE-T(X) & 3 ports 100BASE-FX SC multimode,

943434059

RS20-0900MMM2TDAUHC

unmanaged, Extended Temperature, w/ redundant power inputs & fault

relay





6 ports 10/100BASE-T(X), 2 ports 100BASE-FX SC singlemode & 1 port

943434060

RS20-0900VVM2TDAUHC

100BASE-FX SC multimode, unmanaged, Extended Temperature, w/

redundant power inputs & fault relay



943434061

RS20-0400T1T1SDABHC

2 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-TX. Basic

management without Redundancy Manager built-in*.

943434062

RS20-0400M2M2SDABHC

2 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-FX, multimode, SC

socket. Basic management without Redundancy Manager built-in*.

943434063

RS20-0800T1T1SDABHC

6 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-TX. Basic

management without Redundancy Manager built-in*.

943434064

RS20-0800M2M2SDABHC

6 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-FX, multimode, SC

socket. Basic management without Redundancy Manager built-in*.



943434001

RS20-0400M2M2SDAEHC

2 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-FX, multimode, SC

socket. Enhanced management.

943434066

RS20-0400M4M4SDAEHC

2 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-FX, multimode, ST

socket. Enhanced management.

943434002

RS20-0400M2M2SDAPHC

2 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-FX, multimode, SC

socket. Professional management.

943434007

RS20-0400T1T1SDAEHC

2 ports 10/100BASE-T(X) +, 2 uplink ports 100BASE-TX. Enhanced

management.

943434008

RS20-0400T1T1SDAPHC

2 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-TX. Professional

management.

943434009

RS20-0400M2T1SDAEHC

2 ports 10/100BASE-T(X) + 1 uplink port 100BASE-FX, multimode, SC

socket & 1 uplink port 100BASE-TX. Enhanced mgmt.

943434010

RS20-0400M2T1SDAPHC

2 ports 10/100BASE-T(X) + 1 uplink port 100BASE-FX, multimode, SC

socket & 1 uplink port 100BASE-TX. Professional mgmt.

943434011

RS20-0400S2T1SDAEHC

2 ports 10/100BASE-T(X) + 1 uplink port 100BASE-FX, singlemode, SC

socket & 1 uplink port 100BASE-TX. Enhanced mgmt.

943434012

RS20-0400S2T1SDAPHC

2 ports 10/100BASE-T(X) + 1 uplink port 100BASE-FX, singlemode, SC

socket & 1 uplink port 100BASE-TX. Professional mgmt.

943434013

RS20-0400S2S2SDAEHC

2 ports 10/100BASE-T(X) + 2 uplinks ports 100BASE-FX, singlemode, SC

socket. Enhanced management.

943434014

RS20-0400S2S2SDAPHC

2 ports 10/100BASE-T(X) + 2 uplinks ports 100BASE-FX, singlemode, SC

socket. Professional management.

943434003

RS20-0800M2M2SDAEHC

6 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-FX, multimode, SC

socket. Enhanced management.

943434004

RS20-0800M2M2SDAPHC

6 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-FX, multimode, SC

socket. Professional management.

943434015

RS20-0800M2M2SDHEHC

6 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-FX, multimode, SC

socket. Enhanced management & "H" approval.

943434016

RS20-0800M2M2SDHPHC

6 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-FX, multimode, SC

socket. Professional management & "H" approval.

943434017

RS20-0800M4M4SDAEHC

6 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-FX, multimode, ST

socket. Enhanced management.

943434018

RS20-0800M4M4SDAPHC

6 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-FX, multimode, ST

socket. Professional management.

943434019

RS20-0800S2S2SDAEHC

6 ports 10/100BASE-T(X) + 2 uplinks ports 100BASE-FX, singlemode, SC

socket. Enhanced management.

943434020

RS20-0800S2S2SDAPHC

6 ports 10/100BASE-T(X) + 2 uplinks ports 100BASE-FX, singlemode, SC

socket. Professional management.

943434021

RS20-0800T1T1SDAEHC

6 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-TX. Enhanced

management.

943434022

RS20-0800T1T1SDAPHC

6 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-TX. Professional

management.

943434065

RS20-0800M2T1SDAEHC

6 ports 10/100BASE-T(X) + 1 uplink port 100BASE-FX, multimode, SC

socket & 1 uplink port 100BASE-TX. Professional mgmt.

943434005

RS20-1600M2M2SDAEHC

14 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-FX, multimode, SC

socket. Enhanced management.

943434006

RS20-1600M2M2SDAPHC

14 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-FX, multimode, SC

socket. Professional management.

943434023

RS20-1600T1T1SDAEHC

14 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-TX. Enhanced

management.

943434024

RS20-1600T1T1SDAPHC

14 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-TX. Professional

management.

943434025

RS20-1600M2T1SDAEHC

14 ports 10/100BASE-T(X) + 1 uplink port 100BASE-FX, multimode, SC

socket & 1 uplink port 100BASE-TX. Enhanced mgmt.

943434026

RS20-1600M2T1SDAPHC

14 ports 10/100BASE-T(X) + 1 uplink port 100BASE-FX, multimode, SC

socket & 1 uplink port 100BASE-TX. Professional mgmt.

943434027

RS20-1600S2S2SDAEHC

14 ports 10/100BASE-T(X) + 2 uplinks ports 100BASE-FX, singlemode, SC

socket. Enhanced management.

943434028

RS20-1600S2S2SDAPHC

14 ports 10/100BASE-T(X) + 2 uplinks ports 100BASE-FX, singlemode, SC

socket. Professional management.

943434041

RS20-2400T1T1SDAEHC

22 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-TX. Enhanced

management.

943434042

RS20-2400T1T1SDAPHC

22 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-TX. Professional

management.

943434043

RS20-2400M2M2SDAEHC

22 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-FX, multimode, SC

socket. Enhanced management.

943434044

RS20-2400M2M2SDAPHC

22 ports 10/100BASE-T(X) + 2 uplink ports 100BASE-FX, multimode, SC

socket. Professional management.

943434045

RS20-2400S2S2SDAEHC

22 ports 10/100BASE-T(X) + 2 uplinks ports 100BASE-FX, singlemode, SC

socket. Enhanced management.

943434046

RS20-2400S2S2SDAPHC

22 ports 10/100BASE-T(X) + 2 uplinks ports 100BASE-FX, singlemode, SC

socket. Professional management.

943434029

RS30-0802T1T1SDAEHC

8 ports 10/100BASE-T(X) + 2 Gigabit uplinks 1000BASE-TX, RJ45

connections. Enhanced management.

943434030

RS30-0802T1T1SDAPHC

8 ports 10/100BASE-T(X) + 2 Gigabit uplinks 1000BASE-TX, RJ45

connections. Enhanced management.

943434031

RS30-0802O6O6SDAEHC

8 ports 10/100BASE-T(X) + 2 Gigabit uplinks with SFP slot integrated.

Enhanced mgmt. *SFPs need to be purchased separately.

943434032

RS30-0802O6O6SDAPHC

8 ports 10/100BASE-T(X) + 2 Gigabit uplinks with SFP slot integrated.

Professional mgmt. *SFPs need to be purchased sep.

943434033

RS30-1602T1T1SDAEHC

16 ports 10/100BASE-T(X) + 2 Gigabit uplinks 1000BASE-TX, RJ45

connections. Enhanced management.

943434034

RS30-1602T1T1SDAPHC

16 ports 10/100BASE-T(X) + 2 Gigabit uplinks 1000BASE-TX, RJ45

connections. Enhanced management.

943434035

RS30-1602O6O6SDAEHC

16 ports 10/100BASE-T(X) + 2 Gigabit uplinks with SFP slot integrated.

Enhanced mgmt. *SFPs need to be purchased separately.

943434036

RS30-1602O6O6SDAPHC

16 ports 10/100BASE-T(X) + 2 Gigabit uplinks with SFP slot integrated.

Professional mgmt. *SFPs need to be purchased sep..

943434037

RS30-2402T1T1SDAEHC

24 ports 10/100BASE-T(X) + 2 Gigabit uplinks 1000BASE-TX, RJ45

connections. Enhanced management.

943434038

RS30-2402T1T1SDAPHC

24 ports 10/100BASE-T(X) + 2 Gigabit uplinks 1000BASE-TX, RJ45

connections. Enhanced management.

943434039

RS30-2402O6O6SDAEHC

24 ports 10/100BASE-T(X) + 2 Gigabit uplinks with SFP slot integrated.

Enhanced mgmt. *SFPs need to be purchased separately.

943434040

RS30-2402O6O6SDAPHC

24 ports 10/100BASE-T(X) + 2 Gigabit uplinks with SFP slot integrated.

Professional mgmt. *SFPs need to be purchased sep.





Full Gigabit Rail switch with 9 ports 10/100/1000BASE-T(X): 4 Combo ports

943935001

RS40-0009CCCCSDAEHC

plus 5 TX ports, Enhanced Software enhanced, Standard temperature

range. *SFPs need to be purchased sep.



943971001

RSR, Wall Mounting Plate 120mm

RSR wall mounting plate 120mm

943971003

RSR, Wall Mounting Plate 60mm

RSR wall mounting plate 60mm

943971002

RSR, Wandmontageplatte 90mm

RSR wall mounting plate 90mm





Ruggedized Rail Switch, 6 ports 10/100BAST-T(X) + 2 uplink ports

943953015

RSR20-0800M2M2T1SCCHPHHXX.X.

100BASE-FX Multimode, SC Socket. Standard Temperature, 2 redundant

Power Supplies





Ruggedized Rail Switch, 6 ports 10/100BAST-T(X) + 2 uplink ports

943953016

RSR20-0800M2M2T1SKKHPHHXX.X.

100BASE-FX Multimode, SC Socket. Standard Temperature, 2 redundant

Power Supplies

943953017

RSR20-0800T1T1T1SCCHPHHXX.X.

Ruggedized Rail Switch, 8 ports 10/100BAST-T(X). Standard Temperature,

2 redundant Power Supplies

943953018

RSR20-0800T1T1T1SKKHPHHXX.X.

Ruggedized Rail Switch, 8 ports 10/100BAST-T(X). Standard Temperature,

2 redundant Power Supplies





Ruggedized Rail Switch, 6 ports 10/100BAST-T(X) + 3 uplink ports

943953013

RSR20-0900MMM2T1SCCHPHHXX.X.

100BASE-FX Multimode, SC Socket. Standard Temperature, 2 redundant

Power Supplies





Ruggedized Rail Switch, 6 ports 10/100BAST-T(X) + 3 uplink ports

943953014

RSR20-0900MMM2T1SKKHPHHXX.X.

100BASE-FX Multimode, SC Socket. Standard Temperature, 2 redundant

Power Supplies

943953009

RSR30-0603CCO7T1SCCHPHHXX.X.

Ruggedized Rail Switch, 6 ports 10/100BAST-T(X) + 3 GE Combo ports.

Standard Temperature, 2 redundant Power Supplies

943953010

RSR30-0603CCO7T1SKKHPHHXX.X.

Ruggedized Rail Switch, 6 ports 10/100BAST-T(X) + 3 GE Combo ports.

Standard Temperature, 2 redundant Power Supplies

943953012

RSR30-0703OOO6Z6SK9HPHHXX.X.

Ruggedized Rail Switch, 6 FE SFP slot + 3 GE SFP slot. Standard

Temperature, Single Power Supply

943953001

RSR30-0802CCZZT1SCCHPHHXX.X.

Ruggedized Rail Switch, 6 ports 10/100BAST-T(X) + 2 FE SFP slots + 2 GE

Combo ports. Standard Temperature, 2 redundant Power Supplies

943953002

RSR30-0802CCZZT1SKKHPHHXX.X.

Ruggedized Rail Switch, 6 ports 10/100BAST-T(X) + 2 FE SFP slots + 2 GE

Combo ports. Standard Temperature, 2 redundant Power Supplies

943953005

RSR30-0802O6O6T1SCCHPHHXX.X.

Ruggedized Rail Switch, 8 ports 10/100BAST-T(X) + 2 GE SFP slots.

Standard Temperature, 2 redundant Power Supplies

943953006

RSR30-0802O6O6T1SKKHPHHXX.X.

Ruggedized Rail Switch, 8 ports 10/100BAST-T(X) + 2 GE SFP slots.

Standard Temperature, 2 redundant Power Supplies

943953007

RSR30-0802O7O7T1SCCHPHHXX.X.

Ruggedized Rail Switch, 8 ports 10/100BAST-T(X) + 2 GE Combo ports.

Standard Temperature, 2 redundant Power Supplies

943953008

RSR30-0802O7O7T1SKKHPHHXX.X.

Ruggedized Rail Switch, 8 ports 10/100BAST-T(X) + 2 GE Combo ports.

Standard Temperature, 2 redundant Power Supplies

943953003

RSR30-0802OOZZT1SCCHPHHXX.X.

Ruggedized Rail Switch, 6 ports 10/100BAST-T(X) + 2 FE SFP slots + 2 GE

SFP slots. Standard Temperature, 2 redundant Power Supplies

943953004

RSR30-0802OOZZT1SKKHPHHXX.X.

Ruggedized Rail Switch, 6 ports 10/100BAST-T(X) + 2 FE SFP slots + 2 GE

SFP slots. Standard Temperature, 2 redundant Power Supplies



943435001

MS20-0800SAAEHC

Backplane w/ 2 Media Module slots (8 ports max), Enhanced mgmt.,

requires Media Modules

943435002

MS20-0800SAAPHC

Backplane w/ 2 Media Module slots (8 ports max), Professional mgmt.,

requires Media Modules





Backplane w/ 4 Media Module slots (16 ports, 24 max w/ *MB-2T),

943435003

MS20-1600SAAEHC

Enhanced mgmt., requires Media Modules. *MB-2T needs to be purchased

separately.





Backplane w/ 4 Media Module slots (16 ports, 24 max w/ *MB-2T),

943435004

MS20-1600SAAPHC

Professional mgmt., requires Media Modules. *MB-2T needs to be

purchased separately.

943435005

MS30-0802SAAEHC

Backplane w/ 3 Media Module slots (8 ports max + 2 Gigabit uplinks),

Enhanced management, requires Media Modules

943435006

MS30-0802SAAPHC

Backplane w/ 3 Media Module slots (8 ports max + 2 Gigabit uplinks),

Professional management, requires Media Modules.





Backplane w/ 5 Media Module slots (16 ports, 24 max w/ *MB-2T + 2

943435007

MS30-1602SAAEHC

Gigabit uplinks), Enhanced mgmt., requires Media Modules. *MB-2T needs

to be purchased separately.





Backplane w/ 5 Media Module slots (16 ports, 24 max w/ *MB-2T + 2

943435008

MS30-1602SAAPHC

Gigabit uplinks), Professional mgmt., requires Media Modules. *MB-2T

needs to be purchased separately.





Power MICE Backplane w/ 5 Media Module slots (16 ports, 24 max w/ *MB-

943009101

MS4128-L2PHC

2T + 4 Gigabit uplinks), Layer 2, Professional mgmt., requires Media

Modules. *MB-2T needs to be purchased separately.





Power MICE Backplane w/ 5 Media Module slots (16 ports, 24 max w/ *MB-

943009201

MS4128-L3EHC

2T + 4 Gigabit uplinks), Layer 3, Enhanced mgmt., requires Media Modules.

*MB-2T needs to be purchased separately.





Power MICE Backplane w/ 5 Media Module slots (16 ports, 24 max w/ *MB-

943009301

MS4128-L3PHC

2T + 4 Gigabit uplinks), Layer 3, Professional mgmt., requires Media

Modules. *MB-2T needs to be purchased separately.

MICE - Media Modules



943733102

MB-2T

2-slot (8 ports) backplane extension for all 4+ slot backplanes (only one MB-

2T per backplane)

943842101

MM2-2FXP4

2 ports 100BASE-FX, plastic fiber (POF), SC socket

943938999

MM20-P9P9T1T1SAHC

2 ports 100BASE-FX, plastic fiber (POF), SC socket; 2 Ports 10/100Mbit/s

TP, RJ45

943718101

MM2-2FXM2

2 ports 100BASE-FX, multimode, SC socket

943719101

MM2-2FXS2

2 ports 100 BASE-FX, singlemode, SC socket

943720101

MM2-2FXM3/2TX1

2 ports 10/100BASE-T(X) & 2 ports 100BASE-FX, multimode, MTRJ socket

943721101

MM2-4FXM3

4 ports 100BASE-FX, multimode, MTRJ socket

943722101

MM2-4TX1

4 ports 10/100BASE-T(X), RJ45 connections

943722151

MM2-4TX1-EEC

4 ports 10/100BASE-T(X), RJ45 connections, EEC (-25 to +55ºC)

943117001

MM3-4TX1-RT

4 ports 10/100BASE-T(X), RJ45 connections, support Realtime Ethernet

PTP (IEEE 1588)

943938999

MM21-T1T1T1T1SAHC

4 ports 10/100BASE-T(X), RJ45 connections, support Realtime Ethernet

PTP (IEEE 1588)

943955001

MM3-4TX1-RT EEC

4 ports 10/100BASE-T(X), support Realtime Ethernet PTP (IEEE 1588)

943117002

MM3-2FXM2/2TX1-RT

2 ports 10/100BASE-T(X) & 2 ports 100BASE-FX, multimode, SC socket,

support Realtime Ethernet PTP (IEEE 1588)

943938999

MM21-M2M2T1T1SAHC

2 ports 10/100BASE-T(X) & 2 ports 100BASE-FX, multimode, SC socket,

support Realtime Ethernet PTP (IEEE 1588)


943955002

MM3-2FXM2/2TX1-RT EEC

2 ports 10/100BASE-T(X) & 2 ports 100BASE-FX, multimode, SC socket,

support Realtime Ethernet PTP (IEEE 1588)

943117003

MM3-2FXS2/2TX1-RT

2 ports 10/100BASE-T(X) & 2 port 100BASE-FX, singleimode, SC socket,

support Realtime Ethernet PTP (IEEE 1588)

943938999

MM21-S2S2T1T1SAHC

2 ports 10/100BASE-T(X) & 2 port 100BASE-FX, singleimode, SC socket,

support Realtime Ethernet PTP (IEEE 1588)

943955003

MM3-2FXS2/2TX1-RT EEC

2 ports 10/100BASE-T(X) & 2 port 100BASE-FX, singleimode, SC socket,

support Realtime Ethernet PTP (IEEE 1588)

943117004

MM3-2FLM4/2TX1-RT

2 ports 10BASE-FL, multimode, ST socket & 2 ports 10/100BASET(X),

support Realtime Ethernet PTP (IEEE 1588)

943938999

MM21-F4F4T1T1SAHC

2 ports 10BASE-FL, multimode, ST socket & 2 ports 10/100BASET(X),

support Realtime Ethernet PTP (IEEE 1588)

943760101

MM3-4FLM4

4 ports 10BASE-FL, multimode, ST socket

943761101

MM3-2FXM2/2TX1

2 ports 10/100BASE-T(X) & 2 ports 100BASE-FX, multimode, SC socket

943761151

MM3-2FXM2/2TX1-EEC

2 ports 10/100BASE-T(X) & 2 ports 100BASE-FX, multimode, SC socket,

EEC (-25 to +55ºC)

943762101

MM3-2FXS2/2TX1

2 ports 10/100BASE-T(X) & 2 port 100BASE-FX, singleimode, SC socket

943762151

MM3-2FXS2/2TX1-EEC

2 ports 10/100BASE-T(X) & 2 port 100BASE-FX, singleimode, SC socket,

EEC (-25 to +55ºC)

943763101

MM3-1FXL2/3TX1

3 ports 10/100BASE-T(X) & 1 port 100BASE-FX, long haul singleimode, SC

socket

943764101

MM3-4FXM2

4 ports 100BASE-FX, multimode, SC socket

943835101

MM3-4FXM4

4 ports 100BASE-FX, multimode, ST socket

943836101

MM3-4FXS2

4 ports 100 BASE-FX, singlemode, SC socket

943837101

MM3-2FXM4/2TX1

2 ports 10/100BASE-T(X) & 2 ports 100BASE-FX, multimode, ST socket

943838101

MM3-1FXS2/3TX1

3 ports 10/100BASE-T(X) & 1 port 100BASE-FX, singleimode, SC socket

943838151

MM3-1FXS2/3TX1-EEC

3 ports 10/100BASE-T(X) & 1 port 100BASE-FX, singleimode, SC socket,

EEC (-25 to +55ºC)

943839101

MM3-1FXM2/3TX1

3 ports 10/100BASE-T(X) & 1 port 100BASE-FX, multimodeimode, SC

socket

943840101

MM3-2AUI

2 ports 10BASE-AUI Half-duplex, SUB-D 15pins male

943938999

MM20-A8A89999SAHC

2 ports 100BASE-FX, plastic fiber (POF), SC socket

943841101

MM3-4TX5

4 ports 10/100BASE-T(X) with M12 D-Coding

943843101

MM3-4FXP4

4 ports 100BASE-FX, plastic fiber (POF), SC socket

943938999

MM20-P9P9P9P9SAHC

4 ports 100BASE-FX, plastic fiber (POF), SC socket

943929101

MM3-1FXS2/1FXM2/2TX1

2 ports 10/100BASE-T(X), 1 port 100BASE-FX multimodeimode, 1 port

100BASE-FX singlemode, SC socket

943930101

MM3-1FXLH+/3TX1

3 ports 10/100BASE-T(X) & 1 port 100BASE-FX Long haul+ SC socket





4 ports 10/100/1000 BASE-T(X) with 4 SFP-slots integrated.& 1 SFP

943010001

MM4-4TX/SFP

deactivates 1 RJ45 TX port. For use with MS30-16 and MS4128 only!

SFPs need to be purchased separately.





2 ports 10/100/1000 BASE-T(X) with 2 SFP-slots integrated.& 1 SFP

943622001

MM4-2TX/SFP

deactivates 1 RJ45 TX port. For use with MS30-16 and MS4128 only!

SFPs need to be purchased separately.

943938001

MM20-Z6Z6Z6Z6SAHH

4 ports FE SFP-slots

943938002

MM22-T1T1T1T1SAHH

4 ports 10/100/1000 BASE-T(X) PoE module



943011301

EAGLE mGuard VPN TX/TX

Security Port: Twisted Pair, RJ45 - Open Port: Twisted Pair, RJ45

943011302

EAGLE mGuard VPN TX/MM SC

Security Port: Twisted Pair, RJ45 - Open Port: FX Multimode, SC

943011303

EAGLE mGuard VPN TX/SM SC

Security Port: Twisted Pair, RJ45 - Open Port: FX Singlemode, SC

943011304

EAGLE mGuard VPN TX/LH SC

Security Port: Twisted Pair, RJ45 - Open Port: FX Long Haul, SC

943011305

EAGLE mGuard VPN MM SC/TX

Security Port: FX Multimode, SC - Open Port: Twisted Pair, RJ45

943011306

EAGLE mGuard VPN MM SC/MM SC

Security Port: FX Multimode, SC - Open Port: FX Multimode, SC

943011307

EAGLE mGuard VPN MM SC/SM SC

Security Port: FX Multimode, SC - Open Port: FX Singlemode, SC

943011308

EAGLE mGuard VPN MM SC/LH SC

Security Port: FX Multimode, SC - Open Port: FX Long Haul, SC



943011311

EAGLE mGuard TX/TX

Security Port: Twisted Pair, RJ45 - Open Port: Twisted Pair, RJ45



943011312

EAGLE mGuard TX/MM SC

Security Port: Twisted Pair, RJ45 - Open Port: FX Multimode, SC



943011313

EAGLE mGuard TX/SM SC

Security Port: Twisted Pair, RJ45 - Open Port: FX Singlemode, SC



943011314

EAGLE mGuard TX/LH SC

Security Port: Twisted Pair, RJ45 - Open Port: FX Long Haul, SC



943011315

EAGLE mGuard MM SC/TX

Security Port: FX Multimode, SC - Open Port: Twisted Pair, RJ45



943011316

EAGLE mGuard MM SC/MM SC

Security Port: FX Multimode, SC - Open Port: FX Multimode, SC



943011317

EAGLE mGuard MM SC/SM SC

Security Port: FX Multimode, SC - Open Port: FX Singlemode, SC



943011318

EAGLE mGuard MM SC/LH SC

Security Port: FX Multimode, SC - Open Port: FX Long Haul, SC



943932023

mGuard Anti Virus/1000nodes





943932034

mGuard Anti Virus/1node





943932021

mGuard Anti Virus/200nodes







943932019

mGuard Anti Virus/50nodes







943932017

mGuard VPN-250









943926001

BAT54-Rail

Industrial WLAN AP/AC with two built-in wireless-LAN modules, which can

be set to 2.4 GHz/ 802.11b/g or 5GHz/ 802.11a/h

943959111

BAT54-F

Industrial WLAN AP/AC with two built-in wireless-LAN modules, which can

be set to 2.4 GHz/ 802.11b/g or 5GHz/ 802.11a/h. IP67 outdoor use





Industrial WLAN AP/AC with 2 built-in wireless-LAN modules, which can be

943959101

BAT54-F X2

set to 2.4 GHz/ 802.11b/g or 5GHz/ 802.11a/h. IP67 outdoor use. ATEX

Approval

943966001

BAT54-F, Masthalterungsset

adapter for pole mounting

943926501

BAT54-Rail Client

Industrial WLAN AC with 1 built-in wireless-LAN modules, which can be set

to 2.4 GHz/ 802.11b/g or 5GHz/ 802.11a/h.

943903301

BAT-ANT-8A, 5GHz Omni-Directional

5GHz Omni-Directional Antenna for 802.11a, w/ 1 meter cable

Antenna

943903310

BAT-ANT-TNC-8b/g DS

2,4GHz Polarisation-Diversity-Antenna

943903320

BAT-ANT-N-12 A

5GHz Directional Antenna

943903330

BAT-ANT-TNC-10 A DS

5GHz Polarisation-Diversity-Antenna

943903340

BAT-ANT-N-23/9 A

5GHz Directional Antenna

943903350

BAT-CLB-7-N

"Low signal loss" N to N cable - 7 meters

943903360

BAT-Pigtail

Adaptor N-RPSMA

943903370

BAT Surge Arrestor

Surge Arrestor

943903380

BAT-ANTN-14G

2.4 GHz Directional Antenna w/ pigtail RP-SMA to N, sealing tape & 1m

cable

943903401

BAT-ANT-8G, 2.4 GHz Omni-Directional

2.4 GHz Omni-Directional Antenna for 802.11g, w/ 1 meter cable

Ant.

943903411

BAT-TNC-B-D-085-02

Directional antenna w/out cable - needs BAT-CLB -7 below

943903501

BAT-CLB-7-TNC

"Low signal loss" N to TNC cable - 7 meters

943056111

BAT-TNC-B-D-085-01

Directional antenna w/out cable - needs BAT-CLB -7 below

943903513

BAT-CLB-2-N

Antenna cable 7m, N plug to N plug, ULA 400, Attenuation 2 dB at 2,4GHz,

3dB at 5GHz

943903512

BAT-CLB-2-TNC

Antenna cable 7m, TNC plug to N plug, ULA 400, attenuation 2 dB at

2.4GHz, 3dB at 5GHz

943903371

BAT Surge Arrestor f-f

Surge arrestor N jack to N jack; frequency range 2 GHz - 6 GHz;

attenuation =< 0.2 dB

943903372

BAT Surge Arrestor m-f

Surge arrestor N jack to N jack; frequency range 2 GHz - 6 GHz;

attenuation =< 0.2 dB

943903421

BAT-ANT-N-6ABG

vehicle omni antenna for 2.4 GHz and 5 GHz







Gigabit Ethernet managed stackable switch, 24 ports 10/100/1000BASE-T

943886001

PowerLion-24TP

(RJ-45), 4 of which are combo ports, Layer 3, plus 1 optional I/O module for

10G uplink.

943886201

PowerLION-XM-10G, 10G Optional

10 Gigabit uplink module - requires XENPAK-10G-LR below

module

943886901

XENPAK-10G-LR, 10G Transceiver, 10

10 gigabit transceiver for use with above 10 Gigabit module

km

943886501

PowerLION-XM-C130, Stacking cable,

Stacking cable, 130 cm.

130cm

943886401

PowerLION-XM-C30, Stacking cable,

Stacking cable, 30 cm.

30cm

943970101

M1-8MM-SC

connectors

943970301

M1-8SFP

Module for MACH100, 8 x FE slots

943970201

M1-8SM-SC

connectors

943970001

M1-8TP-RJ45

Module for MACH100, 8 x 10/100BASE-T(X) TP ports

943969401

MACH102-24TP-F

19" Compact, industrial managed workgroup-Switch with 2 × Giga Ethernet

Combo ports + 24 × 10/100 BASE-TX RJ45 ports





19" Compact, industrial managed workgroup-Switch with 2 × Giga Ethernet

943969501

MACH102-24TP-FR

Combo ports + 24 × 10/100 BASE-TX RJ45 ports. Redundant Power

Supplies

943969001

MACH102-8TP

19" Modular, industrial managed workgroup-Switch with 2 × Giga Ethernet

Combo ports + 8 × 10/100 BASE-TX RJ45 ports + 2 Media module slots

943969201

MACH102-8TP-F

19" Compact, industrial managed workgroup-Switch with 2 × Giga Ethernet

Combo ports + 8 × 10/100 BASE-TX RJ45 ports





19" Compact, industrial managed workgroup-Switch with 2 × Giga Ethernet

943969301

MACH102-8TP-FR

Combo ports + 8 × 10/100 BASE-TX RJ45 ports. Redundant Power

Supplies

943969101

MACH102-8TP-R

19" Compact, industrial managed workgroup-Switch with 2 × Giga Ethernet

Combo ports + 8 × 10/100 BASE-TX RJ45 ports.





Layer 2, Professional mgmt chassis w/ 4 slots for M4-Fast Ethernet media





modules. Fixed installed 4 Gigabit Combo ports (TP/SFP slots) and

943859101

MACH4002-48+4G-L2PHC

16x10/100BASE-T(X) ports & Fan module included. Media modules, SPF

and power supply need to be purchased separately.





Layer 3, Enhanced mgmt chassis w/ 4 slots for M4-Fast Ethernet media





modules. Fixed installed 4 Gigabit Combo ports (TP/SFP slots) and

943859201

MACH4002-48+4G-L3EHC

16x10/100BASE-T(X) ports & Fan module included. Media modules, SPF

and power supply need to be purchased separately.





Layer 3, Professional mgmt chassis w/ 4 slots for M4-Fast Ethernet media





modules. Fixed installed 4 Gigabit Combo ports (TP/SFP slots) and

943859301

MACH4002-48+4G-L3PHC

16x10/100BASE-T(X) ports & Fan module included. Media modules, SPF

and power supply need to be purchased separately.





Layer 2, Professional mgmt chassis w/ 2 slots for M4-media modules.





Fixed installed 8Gigabit-ETHERNET combo ports SFP (100/1000Mbit/s) or

943916101

MACH4002-24G-L2PHC

TP (10/100/1000Mbit/s) & Fan module included. Media modules, SPF and

power supply need to be purchased separately.





Layer 3, Enhanced mgmt chassis w/ 2 slots for M4-media modules. Fixed





installed 8Gigabit-ETHERNET combo ports SFP (100/1000Mbit/s) or TP

943916201

MACH4002-24G-L3EHC

(10/100/1000Mbit/s) & Fan module included. Media modules, SPF and

power supply need to be purchased separately.





Layer 3, Professional mgmt chassis w/ 2 slots for M4-media modules.





Fixed installed 8Gigabit-ETHERNET combo ports SFP (100/1000Mbit/s) or

943916301

MACH4002-24G-L3PHC

TP (10/100/1000Mbit/s) & Fan module included. Media modules, SPF and

power supply need to be purchased separately.





Layer 2, Professional mgmt chassis w/ 4 slots for M4-media modules.





Fixed installed 16 Gigabit-ETHERNET ports TP (10/100/1000Mbit/s) and





8Gigabit as combo SFP (100/1000Mbit/s) ports or TP (10/100/1000Mbit/s)

943911101

MACH4002-48G-L2PHC

ports & Fan module included. Media modules, SPF and power supply need

to be purchased separately.





Layer 3, Enhanced mgmt chassis w/ 4 slots for M4-media modules. Fixed





installed 16 Gigabit-ETHERNET ports TP (10/100/1000Mbit/s) and





8Gigabit as combo SFP (100/1000Mbit/s) ports or TP (10/100/1000Mbit/s)

943911201

MACH4002-48G-L3EHC

ports & Fan module included. Media modules, SPF and power supply need

to be purchased separately.







Layer 3, Professional mgmt chassis w/ 4 slots for M4-media modules.





Fixed installed 16 Gigabit-ETHERNET ports TP (10/100/1000Mbit/s) and





8Gigabit as combo SFP (100/1000Mbit/s) ports or TP (10/100/1000Mbit/s)

943911301

MACH4002-48G-L3PHC

ports & Fan module included. Media modules, SPF and power supply need

to be purchased separately.





Layer 2, Professional mgmt chassis w/ 2 slots for M4-media modules.





Fixed installed 3 x10Gigabit XFP sockets and 8 Gigabit TP

943915101

MACH4002-24G+3X-L2PHC

(10/100/1000Mbit/s) & Fan module included. Media modules, SPF and

power supply need to be purchased separately.





Layer 3, Enhanced mgmt chassis w/ 2 slots for M4-media modules. Fixed





installed 3 x10Gigabit XFP sockets and 8 Gigabit TP (10/100/1000Mbit/s) &

943915201

MACH4002-24G+3X-L3EHC

Fan module included. Media modules, SPF and power supply need to be

purchased separately.





Layer 3, Professional mgmt chassis w/ 2 slots for M4-media modules.





Fixed installed 3 x10Gigabit XFP sockets and 8 Gigabit TP

943915301

MACH4002-24G+3X-L3PHC

(10/100/1000Mbit/s) & Fan module included. Media modules, SPF and

power supply need to be purchased separately.





Layer 2, Professional mgmt chassis w/ 4 slots for M4-media modules.





Fixed installed 3 x10Gigabit XFP sockets and 16 Gigabit TP

943878101

MACH4002-48G+3X-L2PHC

(10/100/1000Mbit/s) & Fan module included. Media modules, SPF and

power supply need to be purchased separately.





Layer 3, Enhance mgmt chassis w/ 4 slots for M4-media modules. Fixed





installed 3 x10Gigabit XFP sockets and 16 Gigabit TP (10/100/1000Mbit/s)

943878201

MACH4002-48G+3X-L3EHC

& Fan module included. Media modules, SPF and power supply need to be

purchased separately.





Layer 3, Professional mgmt chassis w/ 4 slots for M4-media modules.





Fixed installed 3 x10Gigabit XFP sockets and 16 Gigabit TP

943878301

MACH4002-48G+3X-L3PHC

(10/100/1000Mbit/s) & Fan module included. Media modules, SPF and

power supply need to be purchased separately.

MACH4002

Media Modules



943863001

M4-8TP-RJ45

8 ports 10/100/1000BASE-TX, RJ-45 connectors Media module for MACH

4000 (1000 MBit/s not with MACH 4002-48+4G)

943864001

M4-FAST 8-SFP

8 x 100BASE-X SFP socket media module for MACH 4000. *SFPs need to

be purchased separately (see below)





8 x 10/100BASE-TX with power supply for terminals for IEEE802.3af (PoE),

943873001

M4-FAST 8TP-RJ45-PoE

max. 100W per MACH 4002 (PoE via data lines) Media module for MACH

4000.







8 x 1000BASE-X with SFP sockets (not with MACH 4002-48+4G) Media

943879001

M4-GIGA 8-SFP

module for MACH 4000. *SFPs need to be purchased separately (see

below)



943869001

M4-AIR

Fan module (included with chassis), has 4 redundant fans w/ fault LED

indication

943964001

M4-AIR-T

Fan module (included with chassis), has 4 redundant fans w/ fault LED

indication. DIP switch to adjust working mode

943875001

M4-P-AC/DC 300W

24V

DC power module for use with external M4-POWER module.

943876001

M4-P-24VDC 300W

48V

DC power module for use with external M4-POWER module.

943877001

M4-P-48VDC 300W

110 - 240V AC power module for use with external M4-POWER module.

943874001

M4-Power

module (more for redundant power), max 3 power modules

943870001

M4-S-AC/DC 300W

24V

DC internal power module (does not offer power redundancy)

943871001

M4-S-24VDC 300W

48V

DC internal power module (does not offer power redundancy)

943872001

M4-S-48VDC 300W

110 - 240V AC internal power module (does not offer power redundancy)

943922001

M4-POWERCABLE

Power cable to connect MACH4002 and M4-Power



943865001

M-FAST SFP-MM/LC

SFP multimode Transceiver, ≈5km (4km) with G50/125µm-fiber

(G62,5/125µm-fiber), LC socket

943866001

M-FAST SFP-SM/LC

SFP singlemode Transceiver, ≈25km with 9u singlemode fiber, LC socket

943867001

M-FAST SFP-SM+/LC

SFP singlemode+ Transceiver, ≈65km with 9u singlemode fiber, LC socket

943868001

M-FAST SFP-LH/LC

SFP singlemode longhaul+ Transceiver, ≈100km with 9u singlemode fiber,

LC socket

943945001

M-FAST SFP-MM/LC EEC

SFP multimode Transceiver, ≈5km (4km) with G50/125µm-fiber

(G62,5/125µm-fiber), LC socket. EEC (-40 to +70ºC)

943946001

M-FAST SFP-SM/LC EEC

SFP singlemode Transceiver, ≈25km with 9u singlemode fiber, LC socket.

EEC (-40 to +70ºC)

943947001

M-FAST SFP-SM+/LC EEC

SFP singlemode+ Transceiver, ≈65km with 9u singlemode fiber, LC

socket. EEC (-40 to +70ºC)

943948001

M-FAST SFP-LH/LC EEC

SFP singlemode longhaul+ Transceiver, ≈100km with 9u singlemode fiber,

LC socket. EEC (-40 to +70ºC)



SFPs (Fiber Transceivers for Gigabit Ethernet)



943896001

M-SFP-SX/LC EEC

≈550m(275m) with G50/125µm-fiber(G62,5/125µm-fiber), multimode with

LC socket (1 x 1000BASE-SX Port)

943897001

M-SFP-LX/LC EEC

≈20km with E9/125 µm-fiber singlemode with LC socket (1 x 1000BASE-LX

Port)

943014001

M-SFP-SX/LC, SFP Transceiver SX

≈550m(275m) with G50/125µm-fiber(G62,5/125µm-fiber), multimode with

LC socket (1 x 1000BASE-SX Port)

943015001

M-SFP-LX/LC, SFP Transceiver LX

≈20km with E9/125 µm-fiber singlemode with LC socket (1 x 1000BASE-LX

Port)

943042001

M-SFP-LH/LC, SFP Transceiver LH

≈70km with E9/125 µm-fiber singlemode with LC socket (1 x 1000BASE-LX

Port)

943898001

M-SFP-LH/LC EEC, SFP Transceiver LH

≈70km with E9/125 µm-fiber singlemode with LC socket (1 x 1000BASE-LX

Port)

943049001

M-SFP-LH+/LC, SFP Transceiver LH+

≈120km with E9/125 µm-fiber singlemode (longhaul) with LC socket (1 x

1000BASE-LX Port)



SFPs (Fiber Transceivers for 10 Gigabit Ethernet)



943917001

M-XFP-SR/LC

μm) or *33m (62,5/125μm)

943919001

M-XFP-LR/LC

XFP singlemode fiber optic 10Gigabit-ETHERNET transceiver (2km)

943920001

M-XFP-ER/LC

XFP singlemode fiber optic 10Gigabit-ETHERNET transceiver (10~40km)

943921001

M-XFP-ZR/LC

XFPsinglemode fiber optic 10Gigabit-ETHERNET transceiver (40~80km)



943055001

HiOPC CD-ROM + Manual

Respective HiVision software permanent license needs to be purchased

separately.

943156025

Ind.HiVision-Operator Ed., 25 Nodes

Network management for monitoring of 25 nodes (IP adresses)

943156050

Ind.HiVision-Operator Ed., 50 Nodes

Network management for monitoring of 50 nodes (IP adresses)

943156100

Ind.HiVision-Operator Ed., 100 Nodes

Network management for monitoring of 100 nodes (IP adresses)

943156250

Ind.HiVision-Operator Ed., 250 Nodes

Network management for monitoring of 250 nodes (IP adresses)

943156500

Ind.HiVision-Operator Ed., 500 Nodes

Network management for monitoring of 500 nodes (IP adresses)

943160025

Upgrade-Ind.HiVision-OperatorEd.-

Network management for monitoring of industrial networks with up to 25

25Nodes

nodes (IP-addresses)

943160050

Upgrade-Ind.HiVision-OperatorEd.-

Network management for monitoring of industrial networks with up to 50

50Nodes

nodes (IP-addresses)

943160100

Upgrade-Ind.HiVision-OperatorEd.-

Network management for monitoring of industrial networks with up to 100

100Node

nodes (IP-addresses)

943160250

Upgrade-Ind.HiVision-OperatorEd.-

Network management for monitoring of industrial networks with up to 250

250Nodes

nodes (IP-addresses)

943160500

Upgrade-Ind.HiVision-OperatorEd.-

Network management for monitoring of industrial networks with up to 500

500Node

nodes (IP-addresses)

943471300

HiVision PC Based Enterprise

License for enterprise module, PC based operating systems

943471305

HiVision PC Based Enterprise-Update

Update for enterprise module, PC based operating systems

943471350

HiVision PC Based Industrial Line

License for IndustrialLine module, PC based operating systems

943471355

HiVision PC Based Industrial Line-

Update for IndustrialLine module, PC based operating systems

Update

943471400

HiVision HPUX Enterprise

License for Enterprise module, operating system HP-UNIX

943471405

HiVision HPUX Enterprise-Update

Update for Enterprise module, operating system HP-UNIX

943471450

HiVision HPUX Industrial Line

Licence for IndustrialLine module, operating system HP-UNIX

943471455

HiVision HPUX Industrial Line-Update

Update for IndustrialLine module, operating system HP-UNIX

943775105

HiOPC Basic License

Software licence for HiOPC networkmanagement and analysis software

suite to integrate SNMP data into OPC applications.

943775305

HiOPC Expert License

Extended functional range in comparison with HiOPC Basic, e.g. User-

Defined Tag Set-up, Network Analyst, MIB Template Generator

943662003

RPS 30, Rail Power Supply

Power supply output 24VDC/1.3A

943662080

RPS 80 EEC

Power supply output 24VDC/3.0A Operating temperature -25 to +70°C

943662120

RPS 120 EEC

Power supply output 24VDC/5.0A, Operating temperature -25 to +70°C

943952001

RPS60/48V EEC

Power Supply output 48VDC/1.25A. Operating temperature -10 to +70°C

943979001

RPS90/48V HV, PoE-Netzteil

48 V DC rail power supply unit

943980001

RPS90/48V LV, PoE-Netzteil

48 V DC rail power supply unit



943845001

Terminal block 5pin + interlock (50pcs)



943845002

Terminal block 6pin + interlock (50pcs)



943845003

Terminal block 5pin green (50pcs)



943845004

Terminal block 4pin black (50pcs)



943845005

Terminal block 3pin (50 pcs)



943845006

Terminal block 6pin (50St.), RS20/RS30



943845007

Terminal block 4pin (50St.), MS20/MS30



943011021

RR-EPL TX/TX

The ETHERNET Powerlink Router EPL-RR provides the controlled access

to ETHERNET Powerlink real- time segments.

943011022

RR-EPL TX/MM SC

The ETHERNET Powerlink Router EPL-RR provides the controlled access

to ETHERNET Powerlink real- time segments.

943222001

Modem Cabel, Sheilded

Cable for connecting an analog-/ ISDN-modem to an Eagle system

943301001

Terminal Cable

Terminal cable for configuring managed rails, MICE and MACH switches

via the RS232 interface of the switch in connection with terminal software

943766002

19" DIN Rail Adapter

19" adapter for mounting of DIN Rail products in 19" racks.

943767001

ML-MS2/MM, Labels for MS2... +MM

Labels for MICE switches (MS2...) and MICE media modules (MM)

943768001

ML-MS3, Labels for MS3...

Labels for MICE switches (MS3...)

943936001

RJ45 Dust-Cover (50 pcs.)

RJ45 Dust-Cover

943942001

SFP Dust-Cover (25 pcs.)

SFP Dust-Cover

280710834

BasicManual ETHERNET deutsch



280720834

Manual Basics Industrial Line Ethernet



English



943951101

M4-RACKMOUNT, Replacement Angle

Spare fixing brackets for assembling the MACH 4000 in a 19" rack

19" (10St.)

943951001

M4-RACKMOUNT-50mm, Special Angle

Longer fixing brackets for assembling the MACH 4000 in a 19" rack, 50 mm

f.19"(10St)

deeper

943943101

MACH1000/100 +50mm Mounting

MACH1000/100 50mm Mounting Bracket

Bracket

943943001

MACH1000/100 Standard Mounting

MACH1000/100 Standard Mounting Bracket

Bracket

943751001

ACA11 AutoConfiguration Adapter

Stores the configuration data of the connected managed RS2, MS2108,

MS3124, MACH3000 switches (RJ11 Interface)

943751002

ACA11-EEC

Stores the configuration data of the connected managed RS2, MS2108,

MS3124, MACH3000 switches (RJ11 Interface). EEC (-40 to +70ºC)

943271001

ACA21-USB, AutoConfiguration Adapter

Stores the configuration data of the connected managed RS20, RS30,

USB

RS40, MS20, MS30, Power MICE, MACH 1000 & 4000 (USB Interface)





Stores the configuration data of the connected managed RS20, RS30,

943271002

ACA21-USB EEC

RS40, MS20, MS30, Power MICE, MACH 1000 & 4000 (USB Interface).

EEC (-40 to +70ºC)

943913001

ACA21-M12

Stores the configuration data of the connected managed OCTOPUS (M12).

IP67

943913002

ACA21-M12 EEC

Stores the configuration data of the connected managed OCTOPUS (M12).

EEC (-40 to +70ºC). IP67



Links:advantech  |   ymgk  |   zol  |   getck  |   getac  |   hsm  |   alicxt  |   tbqj  |   gyjhj  |   Getck  |   apolor  |
  北京捷泰兴业科技有限公司

京公网安备 11011102002119号

京ICP备12049668号-1 > 免责声明: 新广告法规定所有页面不得出现绝对化用词和功能性用词。我司支持新广告法,并在此郑重声明:我司所有页面上的绝对化用词与功能性用词在此声明前全部失效,不作为赔付理由。 本网站展示信息部分内容整理于互联网,仅供参考和交流,著作权归原作者所有,如果侵犯您的版权及其他合法权益,或展现任何违反国家相关法律的内容,请联系13581789724或邮箱wanghaixu123@163.com,我们会在24小时内审核处理删除。如咨询了解表示默认以上条款声明
  Add:Beijing, China HaiDian SuZhou District, Tel:010-82827893,13581789724,13341110535 Fax:010-82827893-8008
